NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
M Series V.35 Printed Circuit Board Connectors (Continued)
Right-Angle Plug
Assembly
1.565±.020
[39.75±0.51
]
.468
[11.89]
2 Plc.
.275
[6.98]
2 Plc.
2.000±.020
[50.80±0.51
1.687
[42.85]
]
Material and Finish
Housing - Flame retardant
phenolic or polyester, black
Contacts—Brass, plated:
a) .000030 [0.00076] gold
min. in mating area, .000050
[0.00127] nickel min. under-
plating overall
.365
[9.27]
2 Plc.
.375
[9.52]
Typ.
.750
[19.05]
Contact Spring - Stainless
steel
.843
[21.41]
.002
0.05
.054
[1.37
Contact Post—Brass, tin
plated
] Dia.
.005
.125
34 Plc.
0.13
]
Dia.
[3.18
2 Plc.
.600
Mounting Bracket - Brass,
tin-nickel plated or zinc,
nickel plated
NN
JJ
DD
Z
MM
HH
CC
Y
[15.24]
.525
[13.34]
KK
EE
AA
W
S
LL
.450
[11.43]
.375
[9.53]
FF
BB
X
.300
[7.62]
Boardlocks - Copper alloy, tin
plated
.225
[5.72]
.150
[3.81]
.075
[1.91]
.000
[0.00]
Location WafervPhenolic
V
U
.075
[1.91]
T
Nuts and Lockwashers -
Steel, zinc plated
.150
[3.81]
P
R
.225
[5.72]
M
N
J
.300
[7.62]
L
K
E
A
.375
[9.53]
Jackscrews - Stainless steel
H
.450
[11.43]
F
.525
[13.34]
C
D
.600
[15.24]
B
.843
[21.41]
Note: Pc board layouts and connector dimen-
sions illustrated above serve as a guide only; they
are not to be used for actual design or construc-
tion of customer equipment. Consult AMP
customer drawings for latest detailed pc board
layout and connector dimension requirements.
B
A
Recommended PC Board Hole Pattern
(All dimensions typical)
Dimensions
No. of
Pos.
Mounting
Bracket
Housing
Material
Part
Number
Boardlocks
Select Load Pattern
A
B
Brass, Tin
.555
34
34
*
No
Phenolic
Fully Loaded
Fully Loaded
213289-2
213513-4
Nickel Plated
14.10
Zinc, Nickel
Plated
.572
14.53
.347
8.81
Yes
Phenolic
*The mounting bracket has an elongated slot for a 4-40 screw that will accommodate a .330 [8.38] or .347 [8.81] footprint.
Note: Other select loaded configurations can be made available; consult Tyco Electronics Corporation.
Dimensions
No. of
Pos.
Mounting
Bracket
Housing
Material
Part
Number
Boardlocks
Select Load Pattern
A
B
.572
.347
Zinc, Nickel
Plated
34
Yes
Polyester
Polyester
Fully Loaded
213808-3
14.53
8.81
—
18
No Hardware Supplied
A, B, C, D, E, F, H, K, P, R, S, T, U, V, W, X, Y, AA 213808-4
Note: Other select loaded configurations can be made available; consult Tyco Electronics Corporation.
65
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
Dimensions are shown for USA: 1-800-522-6752
reference purposes only. Canada: 1-905-470-4425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
Specifications subject
Mexico: 01-800-733-8926
www.tycoelectronics.com equivalent U.S. Customary Units. to change.
C. America: 52-55-5-729-0425 UK: 44-141-810-8967
MACOM [ Tyco Electronics ]
