NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
M Series V.35 Cable Connectors (Continued)
Cable Connector Kits,
34 Position, Phenolic
(Continued)
Long Screw (2)
Material and Finish
Housing - Flame retardant
phenolic, black
Shield - Zinc, nickel plated
Screws - Steel, zinc plated
Jackscrews - Stainless steel
or zinc, nickel plated
Male
Jackscrew
Cable
Clamp
Cable Clamp - Steel, nickel
plated
Two-Piece
Shield
Kits include:
ꢀHousing
ꢀTwo-piece shield
ꢀOne-piece turnable
jackscrews
Pin Hood
ꢀTwo cable clamp
inserts
ꢀMounting screws
Female
Jackscrew
Notes:
1. Plug and receptacle con-
nector kits come partially
assembled.
Short Screw (4)
Connector
Housing
2. Plug connector kits are
available with or without
pin hoods.
3. Housings are keyed to fix
the proper location of the
male and female jack-
screw as defined by
408-2593.
Kit Part Numbers
Pin
Cable Dia.
Range
Jackscrew
Type
4. Choice of stainless steel or
zinc die cast one-piece
jacksrews.
Hood
Receptacle
Plug
.400-.600
10.16-15.24
.250-.400
6.35-10.16
.400-.600
10.16-15.24
.250-.400
6.35-10.16
.400-.600
10.16-15.24
.400-.600
10.16-15.24
.250-.400
6.35-10.16
.400-.600
10.16-15.24
No
No
Yes
Yes
No
No
No
No
No
Yes
No
Zinc
Zinc
—
213684-1
5. Pin and socket contacts
sold separately. Size 16,
Type III+ contacts are
listed on page 31.
—
213684-2
213684-3
213684-4
213684-7
—
Zinc
—
—
Zinc
Stainless Steel
Zinc
—
213685-1
213685-2
213685-3
213685-5
—
Zinc
—
Stainless Steel
Zinc
—
.150-.300
3.81-7.62
.150-.300
3.81-7.62
.150-.300
3.81-7.62
—
Zinc
213684-9
1-213684-0
Zinc
—
70
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
