NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
M Series V.35 Printed Circuit Board Connectors (Continued)
.468
[11.89]
2 Plc.
.915
[23.24]
Vertical Plug Assembly
1.686
[42.82]
2.000±.020
[50.80±0.51
]
Material and Finish
Housing - Flame retardant
phenolic, black
Contacts - Brass, plated:
a) .000030 [0.00076] gold
min. in mating area, .000050
[0.00127] nickel min. under-
plating overall
.365
[9.27]
2 Plc.
.750
[19.05]
Contact Spring - Stainless
steel
Contact Post - Brass, tin-lead
plated
Nuts and Lockwashers -
Steel, zinc plated
.005
0.13
.125
[3.18
]
Dia.
2 Plc.
Spacers - Stainless steel
.843
21.41]
Jackscrews - Stainless steel
.600
[15.24]
MM
HH
CC
Y
NN
JJ
DD
Z
.525
13.34]
KK
EE
AA
W
S
LL
.450
[11.43]
.375
9.53]
FF
BB
X
.300
[7.62]
.225
5.72]
.150
[3.81]
.075
1.91]
.000
[0.00]
U
V
.075
1.91]
T
.150
[3.81]
P
R
.225
5.72]
M
N
J
.300
[7.62]
K
E
A
L
.375
9.53]
H
.450
[11.43]
F
.525
13.34]
C
D
.600
[15.24]
B
.002
0.05
34 Plc.
.054
[1.37
] Dia.
.843
21.41]
Note: Pc board layouts and connector dimen-
sions illustrated above serve as a guide only;
they are not to be used for actual design or
construction of
customer equipment. Consult Tyco Electronics
customer drawings for latest detailed pc board
layout and connector dimension requirements.
Recommended PC Board Hole Pattern
(All dimensions typical)
No. of
Pos.
Mounting
Hardware
Part
Number
Select Load Pattern
19
Spacers*
A, B, C, D, E, F, K, L, N, P, R, S, T, U, V, W, X, Y, AA
Fully Loaded
213550-4
213550-5
34
Spacers*
*Jackscrews and spacers are provided unassembled.
Note: Other select loaded configurations can be made available, consult Tyco Electronics Corporation.
67
