NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
M Series V.35 Printed Circuit Board Connectors
Right-Angle
Receptacle Assembly
.468
[11.89]
2 Plc.
1.565
[39.75]
.275
[6.98]
2 Plc.
2.000±.020
[50.80±0.51
]
1.687
[42.85]
Material and Finish
Housing—Flame retardant
phenolic or polyester, black
Contacts—Brass, plated:
a) .000030 [0.00076] gold
min. in
mating area, .000050
[0.00127] nickel min. under-
plating overall
.375
[9.52]
Ref.
.365
[9.27]
2 Plc.
.750
[19.05]
(For Recommended PC Board Hole Pattern see page 65)
Contact Spring—Stainless
steel
Contact Post—Brass, tin
plated
Boardlocks—Copper alloy, tin
plated
Mounting Bracket—Brass,
tin-nickel plated or zinc,
nickel plated
Location Wafer—Phenolic
Nuts and Lockwashers—
Steel, zinc plated
Jackscrews—Stainless steel
PCB
Dimensions
No. of
Pos.
Mounting
Bracket
Housing
Material
Part
Number
Boardlocks
Select Load Pattern
A
B
.555
34
14
*
No
No
Phenolic Fully Loaded
2-212810-0
2-212810-4
2-212810-7
1-213574-1
1-213574-2
1-213574-3
1-213574-4
1-213574-5
14.10
Brass,
Tin-Nickel
Plated
.555
14.10
.555
14.10
*
*
Phenolic B, C, D, E, F, H, P, R, S, T, V, X, Y, AA
A, B, C, D, E, F, H, J, P, R, S, T, U, V, W, X, Y,
Phenolic
27
34
17
No
AA, BB, CC, DD, FF, HH, JJ, KK, LL, NN
.572
14.53
.572
14.53
.572
14.53
.572
14.53
.347
8.81
.347
8.81
.347
8.81
.347
8.81
Yes
Yes
Yes
Yes
Yes
Phenolic Fully Loaded
Phenolic A, B, C, D, E, F, H, P, R, S, T, U, V, W, X, Y, AA
Zinc,
Nickel
Plated
A, B, C, D, E, F, H, J, K, L, N, P, R, S, T, U, V, W, X, Y,
AA, BB, NN
23
22
22
Phenolic
Phenolic A, B, C, D, E, F, H, K, L, N, P, R, S, T, U, V, W, X, Y, AA, BB, NN
Phenolic A, B, C, D, E, F, H, J, L, N, P, R, S, T, U, V, W, X, Y, AA, HH, NN
.555
14.10
.330
8.38
PCB
Dimensions
No. of
Pos.
Mounting
Bracket
Housing
Part
Number
Boardlocks
Select Load Pattern
Material
A
B
Brass,
.555
No
No
No
Polyester Fully Loaded
1-213806-0
1-213806-3
1-213806-1
34
34
19
*
*
*
Tin-Nickel Plated 14.10
None
Brass,
Tin-Nickel Plated 14.10
—
.555
Polyester Fully Loaded
A, B, C, D, E, F, H, J, L, P,
Hardware Supplied Unassembled
No Hardware Supplied
Polyester
R, S, T, U, V, W, X, Y, AA
A, B, C, D, E, F, H, K, P,
R, S, T, U, V, W, X, Y, AA
18
34
23
None
—
*
—
Polyester
1-213806-2
213977-9
Zinc,
Nickel Plated
.572
14.53
.347
8.81
Yes
Yes
Polyester Fully Loaded
Zinc,
Nickel Plated
.572
14.53
.347
8.81
Polyester A, B, C, D, E, F, H, J, K, L, N, P, R, S, T, U, V, W, X, Y, AA, BB, NN 213977-7
Polyester A, B, C, D, E, F, H, J, L, N, P, R, S, T, U, V, W, X, Y, AA, HH, KK, NN 213977-8
Zinc,
Nickel Plated
.572
14.53
.347
8.81
23
17
Yes
Yes
Zinc,
Nickel Plated
.572
14.53
.347
8.81
Polyester A, B, C, D, E, F, H, P, R, S, T, U, V, W, X, Y, AA
1-213807-0
*The mounting bracket has an elongated slot for a 4-40 screw that will accommodate a .330 [8.38] or .347 [8.81] footprint.
Note: Other select loaded configurations can be made available; consult Tyco Electronics Corporation.
