ST150S
Phase Control Thyristors
STUD VERSION
Liujing rectifier co., Ltd.
FEATURES
TYPICAL APPLICATIONS
1). Center amplifying gate
1). DC motor controls
2). Hermetic metal case with ceramic insulator
(Also available with glass-metal seal up to 1200V)
3). International standard case TO-209AB (TO-94)
4). Threaded studs UNF 3/4 - 16UNF2A or ISO M16x1.5
5). Compression Bonded Encapsulation for heavy duty
operations such as severe thermal cycling
2). Controlled DC power supplies
3). AC controllers
MAJOR RATINGS AND CHARACTERISTICS
Parameters
ST150S
Unit
150
85
A
IF(AV)
IF(RMS)
IFSM
@ TC
360
A
@ 50Hz
5700
A
@ 60Hz
@ 50Hz
@ 60Hz
5970
A
163
KA2s
KA2s
V
I2t
149
VDRM/VRRM
400 to 1600
100
μ
typical
Tq
TJ
s
40 to 125
ELECTRICAL SPECIFICATIONS
1). Voltage Ratings
VDRM/VRRM, maximum
repetitive peak
VRSM, maximum non-
I
DRM/IRRM max.
repetitive peak
reverse voltage
Type number
Voltage Code
@ TJ = TJ max
reverse voltage
mA
V
V
04
08
12
14
16
400
500
800
900
1200
1400
1600
1300
1500
1700
ST150S
30
