ML145155
Serial–Input PLL
Frequency Synthesizer
Interfaces with Single–Modulus Prescalers
Legacy Device: Motorola/Freescale MC145155-2
The ML145155 is programmed by a clocked, serial input,
16–bit data stream. The device features consist of a reference
oscillator, selectable–reference divider, digital–phase detector,
14–bit programmable divide–by–N counter, and the necessary
shift register and latch circuitry for accepting serial input
data.
P DIP 18 = VP
PLASTIC DIP
CASE 707
18
1
• Operating Temperature Range: T = – 40 to 85°C
• Low Power Consumption Through Use of CMOS
Technology
A
SOG 20W = -6P
SOG PACKAGE
CASE 751D
20
1
• 3.0 to 9.0 V Supply Range
• On– or Off–Chip Reference Oscillator Operation with
Buffered Output
• Compatible with the Serial Peripheral Interface (SPI) on
CMOS MCUs
CROSS REFERENCE/ORDERING INFORMATION
PACKAGE
MOTOROLA
LANSDALE
P DIP 18
MC145155P2
ML145155VP
SOG 20W
MC145155DW2 ML145155-6P
• Lock Detect Signal
Note: Lansdale lead free (Pb) product, as it
becomes available, will be identified by a part
number prefix change from ML to MLE.
• Two Open–Drain Switch Outputs
• 8 User–Selectable ÷ R Values: 16, 512, 1024, 2048,
3668, 4096, 6144, 8192
• Single Modulus/Serial Programming
• ÷ N Range = 3 to 16383
• “Linearized” Digital Phase Detector Enhances Transfer
Function Linearity
• Two Error Signal Options: Single–Ended (Three–State)
or Double–Ended
• Chip Complexity: 6504 FETs or 1626 Equivalent Gates
PIN ASSIGNMENTS
PLASTIC DIP
SOG PACKAGE
RA1
RA2
1
2
3
4
5
6
18
17
16
15
14
13
RA0
OSC
OSC
REF
RA1
RA2
1
2
20
19
RA0
OSC
in
in
φ
φ
3
4
18
OSC
V
out
V
out
φ
17
REF
φ
R
out
R
out
V
5
6
16
15
NC
V
SW2
DD
out
DD
PD
SW2
SW1
ENB
DATA
CLK
PD
SW1
ENB
DATA
CLK
out
V
7
14
13
12
11
V
7
8
9
12
11
10
SS
NC
SS
LD
8
LD
9
f
in
f
10
in
NC = NO CONNECTION
Page 9 of 35
www.lansdale.com
Issue A
