D Subminiature
Filter D
D*JT Filter Performance
D*JT Electrical Data
Voltage rating (working) 200 VDC/120 Vrms, 400 Hz
Current rating 5 A (Size 20 contacts), 30 A (Size 8 contacts)
Insulation resistance,
electrification time 30 s, temperature 25°C 10,000 Mȉ min./100 V
Dielectric Withstanding Voltage (Sea Level)
500 micro amps max. charge/discharge 500 VDC
Filter type C Capacitor
Filter symbol per DIN
Filter designation
9
5
4
6
1
2
3
Capacitance, type
at 1 KHz, 0,1 Vrms, 25°C
47000 pF
5000 pF
2000 pF
1500 pF
1000 pF
500 pF
250 pF
Frequency
MHz
Attenuation
db min.
Attenuation
db min.
Attenuation
db min.
Attenuation
db min.
Attenuation
db min.
Attenuation
db min.
Attenuation
db min.
5
10
30
37
50
45
—
—
11
16
35
54
64
64
6
10
27
48
60
64
3
7
—
5
—
2
—
1
100
23
46
—
—
20
42
60
64
16
37
60
64
14
35
60
64
1000
2000
5000
Attenuation per MIL-STD-220 at 25°C with no applied voltage or current
Dimensions are shown in mm (inch)
Dimensions subject to change
107
