Package Mechanical Specifications and Pin Information
Signal Name
Type
Description
VCCSENSE is an isolated low impedance connection to processor
core power (VCC). It can be used to sense or measure power near
the silicon with little noise. Please contact your Intel
VCC_SENSE
O
representative for more implementation details.
VSS_SENSE is an isolated low impedance connection to processor
core VSS. It can be used to sense or measure ground near the
silicon with little noise. Please contact your Intel representative
for more implementation details.
VSS_SENSE
O
§
Datasheet
49
