Electrical Specifications
Table 11. Open Drain Signal Group DC Specifications
Symbol
Parameter
Min
Typ
Max
Unit
Notes1
VOH
VOL
IOL
Output High Voltage
Output Low Voltage
Output Low Current
VCCP-–5%
VCCP
—
VCCP+5%
0.20
V
V
3
0
16
—
50
mA
2
4
5
Output Leakage
Current
ILO
—
—
±200
2.45
µA
pF
Cpad
Pad Capacitance
1.9
2.2
NOTES:
1.
2.
3.
4.
5.
Unless otherwise noted, all specifications in this table apply to all processor frequencies.
Measured at 0.2 VCCP
VOH is determined by value of the external pull-up resistor to VCCP
For Vin between 0 V and VOH
.
.
.
Cpad includes die capacitance only. No package parasitics are included.
§
32
Datasheet
