LXT971A 3.3V Dual-Speed Fast Ethernet Transceiver
Table 51. Auto-Negotiation Link Partner Next Page Receive Register (Address 8)
Bit
Name
Description
Type 1
Default
1 = Link Partner has additional next pages to send
Next Page
(NP)
8.15
RO
0
0 = Link Partner has no additional next pages to
send
1 = Link Partner has received Link Code Word from
LXT971A
Acknowledge
(ACK)
8.14
RO
0
0 = Link Partner has not received Link Code Word
from LXT971A
1 = Page sent by the Link Partner is a Message
Page
Message Page
(MP)
8.13
8.12
RO
RO
0
0
0 = Page sent by the Link Partner is an Unformatted
Page
Acknowledge 2
(ACK2)
1 = Link Partner complies with the message
0 = Link Partner cannot comply with the message
1 = Previous value of the transmitted Link Code
Word equalled logic zero
Toggle
(T)
8.11
RO
RO
0
0
0 = Previous value of the transmitted Link Code
Word equalled logic one
Message/Unformatted
Code Field
User definable
8.10:0
1. RO = Read Only.
80
Datasheet
Document #: 249414
Revision #: 002
Rev. Date: August 7, 2002
