Host-PCI Express* Bridge Registers (D1:F0)
(Intel® 82915G/82915P/82915PL Only)
R
8.1.44
PEGLC—PCI Express*-G Legacy Control
PCI Device:
Address Offset:
Default Value:
Access:
1
ECh
00000000h
RO, R/W
32 bits
Size:
This register controls functionality that is needed by Legacy (non-PCI Express aware) OS’s
during run time.
Bit
Access &
Default
Description
31:3
RO
Reserved
0000
0000h
2
1
0
R/W
0b
PME GPE Enable (PMEGPE):
0 = Do not generate GPE PME message when PME is received.
1 = Enable. Generate a GPE PME message when PME is received
(Assert_PMEGPE and Deassert_PMEGPE messages on DMI). This enables
the (G)MCH to support PMEs on the PCI Express* x16 Graphics Interface
port under legacy OSs.
R/W
0b
Hot-Plug GPE Enable (HPGPE)
0 = Do not generate GPE Hot-Plug message when Hot-Plug event is received.
1 = Enable. Generate a GPE Hot-Plug message when Hot-Plug Event is received
(Assert_HPGPE and Deassert_HPGPE messages on DMI). This enables the
(G)MCH to support Hot-Plug on the PCI Express* x16 Graphics Interface port
under legacy OSs.
R/W
0b
General Message GPE Enable (GENGPE)
0 = Do not forward received GPE assert/deassert messages.
1 = Enable. Forward received GPE assert/deassert messages. These general
GPE message can be received via the PCI Express* x16 Graphics Interface
port from an external Intel device and will be subsequently forwarded to the
Intel® ICH6 (via Assert_GPE and Deassert_GPE messages on DMI).
162
Datasheet
