Graphics, Video, and Display (D2:F0)
9.4.12
9.4.13
SS—Subsystem Identifiers
This register matches the value written to the LPC bridge.
CAP_PTR—Capabilities Pointer Register
Register Address:
Default Value:
34h
00D0h
Attribute:
Size:
RO, R/W
8 bits
Default
Bit
and
Description
Access
D0h
RO
Pointer (PTR): This field contains an offset into the function's PCI
Configuration Space for the first item in the New Capabilities Linked List.
7:0
9.4.14
INT_LN—Interrupt Line Register
Register Address:
Default Value:
3Ch
00h
Attribute:
Size:
RO, R/W
8 bits
Default
Bit
and
Description
Access
Interrupt Line (ILIN): Software written value to indicate which
interrupt line (vector) the interrupt is connected to. No hardware action is
taken on this bit.
00h
R/W
7:0
9.4.15
INT_PN—Interrupt Pin Register
Register Address:
Default Value:
3Dh
See Description
Attribute:
Size:
RO
16 bits
Default
Bit
and
Description
Access
Desc
RO
Interrupt Pin (IPIN): This value reflects the value of D02IP.GP in the
LPC configuration space.
7:0
Datasheet
109
