XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
128 P10.14
Ctrl. Type Function
O0 / I St/B Bit 14 of Port 10, General Purpose Input/Output
U1C0_
SELO1
O1
St/B USIC1 Channel 0 Select/Control 1 Output
U0C1_DOUT O2
RD OH
U0C1_DX0C I
RxDC3C
129 P1.4
St/B USIC0 Channel 1 Shift Data Output
St/B External Bus Interface Read Strobe Output
St/B USIC0 Channel 1 Shift Data Input
St/B CAN Node 3 Receive Data Input
I
O0 / I St/B Bit 4 of Port 1, General Purpose Input/Output
CCU62_
COUT61
O1
O2
O3
St/B CCU62 Channel 1 Output
U1C1_
SELO4
St/B USIC1 Channel 1 Select/Control 4 Output
St/B USIC2 Channel 0 Select/Control 5 Output
U2C0_
SELO5
A12
OH
I
St/B External Bus Interface Address Line 12
St/B USIC2 Channel 0 Shift Control Input
U2C0_DX2B
130 P10.15
O0 / I St/B Bit 15 of Port 10, General Purpose Input/Output
U1C0_
SELO2
O1
St/B USIC1 Channel 0 Select/Control 2 Output
U0C1_DOUT O2
U1C0_DOUT O3
St/B USIC0 Channel 1 Shift Data Output
St/B USIC1 Channel 0 Shift Data Output
ALE
U0C1_DX1C I
131 P1.5
OH
St/B External Bus Interf. Addr. Latch Enable Output
St/B USIC0 Channel 1 Shift Clock Input
O0 / I St/B Bit 5 of Port 1, General Purpose Input/Output
CCU62_
COUT60
O1
St/B CCU62 Channel 0 Output
U1C1_
SELO3
O2
St/B USIC1 Channel 1 Select/Control 3 Output
BRKOUT
A13
O3
St/B OCDS Break Signal Output
OH
St/B External Bus Interface Address Line 13
St/B USIC2 Channel 0 Shift Data Input
U2C0_DX0C I
Data Sheet
30
V0.91, 2007-02
Draft Version
