XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
112 P9.0
Ctrl. Type Function
O0 / I St/B Bit 0 of Port 9, General Purpose Input/Output
O1 / I St/B CCU63 Channel 0 Input/Output
CCU63_
CC60
113 P10.8
O0 / I St/B Bit 8 of Port 10, General Purpose Input/Output
U0C0_
O1
St/B USIC0 Channel 0 Master Clock Output
MCLKOUT
U0C1_
SELO0
O2
St/B USIC0 Channel 1 Select/Control 0 Output
AD8
OH / I St/B External Bus Interface Address/Data Line 8
CCU60_
I
St/B CCU60 Position Input 1
CCPOS1A
U0C0_DX1C I
BRKIN_B
114 P9.1
St/B USIC0 Channel 0 Shift Clock Input
St/B OCDS Break Signal Input
I
O0 / I St/B Bit 1 of Port 9, General Purpose Input/Output
O1 / I St/B CCU63 Channel 1 Input/Output
CCU63_
CC61
115 P10.9
O0 / I St/B Bit 9 of Port 10, General Purpose Input/Output
U0C0_
SELO4
O1
St/B USIC0 Channel 0 Select/Control 4 Output
U0C1_
O2
St/B USIC0 Channel 1 Master Clock Output
MCLKOUT
AD9
OH / I St/B External Bus Interface Address/Data Line 9
CCU60_
I
St/B CCU60 Position Input 2
CCPOS2A
TCK_B
I
St/B JTAG Clock Input
Data Sheet
26
V0.91, 2007-02
Draft Version
