XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
Ctrl. Type Function
78
P2.7
O0 / I St/B Bit 7 of Port 2, General Purpose Input/Output
U0C1_
SELO0
O1
St/B USIC0 Channel 1 Select/Control 0 Output
U0C0_
SELO1
O2
St/B USIC0 Channel 0 Select/Control 1 Output
CC2_4
A20
O3 / I St/B CAPCOM2 CC4IO Capture Inp./ Compare Out.
OH
St/B External Bus Interface Address Line 20
St/B USIC0 Channel 1 Shift Control Input
St/B CAN Node 1 Receive Data Input
U0C1_DX2C I
RxDC1C
P0.1
I
79
O0 / I St/B Bit 1 of Port 0, General Purpose Input/Output
U1C0_DOUT O1
St/B USIC1 Channel 0 Shift Data Output
St/B CAN Node 0 Transmit Data Output
TxDC0
O2
CCU61_
CC61
O3 / I St/B CCU61 Channel 1 Input/Output
A1
OH
St/B External Bus Interface Address Line 1
St/B USIC1 Channel 0 Shift Data Input
St/B USIC1 Channel 0 Shift Clock Input
U1C0_DX0B
U1C0_DX1A
P2.8
I
I
80
O0 / I DP/B Bit 8 of Port 2, General Purpose Input/Output
U0C1_
O1
DP/B USIC0 Channel 1 Shift Clock Output
SCLKOUT
EXTCLK
O2
DP/B Programmable Clock Signal Output
1)
CC2_5
A21
O3 / I DP/B CAPCOM2 CC5IO Capture Inp./ Compare Out.
OH
DP/B External Bus Interface Address Line 21
DP/B USIC0 Channel 1 Shift Clock Input
U0C1_DX1D I
P4.7
81
O0 / I St/B Bit 7 of Port 4, General Purpose Input/Output
O3 / I St/B CAPCOM2 CC15IO Capture Inp./ Compare Out.
CC2_15
T4EUD
I
St/B GPT1 Timer T4 External Up/Down Control Input
