XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
Ctrl. Type Function
95
P10.3
O0 / I St/B Bit 3 of Port 10, General Purpose Input/Output
O2 St/B CCU60 Channel 0 Output
CCU60_
COUT60
AD3
OH / I St/B External Bus Interface Address/Data Line 3
U0C0_DX2A
U0C1_DX2A
P0.5
I
I
St/B USIC0 Channel 0 Shift Control Input
St/B USIC0 Channel 1 Shift Control Input
96
O0 / I St/B Bit 5 of Port 0, General Purpose Input/Output
U1C1_
SCLKOUT
O1
O2
O3
St/B USIC1 Channel 1 Shift Clock Output
St/B USIC1 Channel 0 Select/Control 2 Output
St/B CCU61 Channel 2 Output
U1C0_
SELO2
CCU61_
COUT62
A5
OH
I
St/B External Bus Interface Address Line 5
St/B USIC1 Channel 1 Shift Clock Input
U1C1_DX1A
U1C0_DX1C I
P3.3
St/B USIC1 Channel 0 Shift Clock Input
97
O0 / I St/B Bit 3 of Port 3, General Purpose Input/Output
U2C0_
SELO0
O1
St/B USIC2 Channel 0 Select/Control 0 Output
U2C1_
SELO1
O2
St/B USIC2 Channel 1 Select/Control 1 Output
U2C0_DX2A
RxDC3A
P10.4
I
I
St/B USIC2 Channel 0 Shift Control Input
St/B CAN Node 3 Receive Data Input
98
O0 / I St/B Bit 4 of Port 10, General Purpose Input/Output
U0C0_
SELO3
O1
St/B USIC0 Channel 0 Select/Control 3 Output
CCU60_
COUT61
O2
St/B CCU60 Channel 1 Output
AD4
OH / I St/B External Bus Interface Address/Data Line 4
U0C0_DX2B
U0C1_DX2B
I
I
St/B USIC0 Channel 0 Shift Control Input
St/B USIC0 Channel 1 Shift Control Input
Data Sheet
22
V0.91, 2007-02
Draft Version
