XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
Ctrl. Type Function
63
P4.1
O0 / I St/B Bit 1 of Port 4, General Purpose Input/Output
O2 St/B CAN Node 2 Transmit Data Output
O3 / I St/B CAPCOM2 CC9IO Capture Inp./ Compare Out.
OH St/B External Bus Interface Chip Select 1 Output
O0 / I St/B Bit 4 of Port 2, General Purpose Input/Output
TxDC2
CC2_9
CS1
64
P2.4
U0C1_DOUT O1
St/B USIC0 Channel 1 Shift Data Output
Note: Not available in step AA.
TxDC0
CC2_1
A17
O2
St/B CAN Node 0 Transmit Data Output
O3 / I St/B CAPCOM2 CC1IO Capture Inp./ Compare Out.
OH
St/B External Bus Interface Address Line 17
St/B USIC0 Channel 0 Shift Data Input
St/B CAN Node 1 Receive Data Input
U0C0_DX0F
RxDC1A
P11.1
I
I
65
66
67
O0 / I St/B Bit 1 of Port 11, General Purpose Input/Output
St/B CCU63 Position Input 1
CCU63_
I
CCPOS1A
P11.0
O0 / I St/B Bit 0 of Port 11, General Purpose Input/Output
St/B CCU63 Position Input 0
CCU63_
CCPOS0A
I
P2.5
O0 / I St/B Bit 5 of Port 2, General Purpose Input/Output
U0C0_
O1
St/B USIC0 Channel 0 Shift Clock Output
SCLKOUT
TxDC0
CC2_2
A18
O2
St/B CAN Node 0 Transmit Data Output
O3 / I St/B CAPCOM2 CC2IO Capture Inp./ Compare Out.
OH
I
St/B External Bus Interface Address Line 18
St/B USIC0 Channel 0 Shift Clock Input
U0C0_DX1D
P4.2
68
O0 / I St/B Bit 2 of Port 4, General Purpose Input/Output
O2 St/B CAN Node 2 Transmit Data Output
O3 / I St/B CAPCOM2 CC10IO Capture Inp./ Compare Out.
TxDC2
CC2_10
CS2
OH
I
St/B External Bus Interface Chip Select 2 Output
St/B GPT1 Timer T2 Count/Gate Input
T2IN
Data Sheet
16
V0.91, 2007-02
Draft Version
