XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
Ctrl. Type Function
47
P5.12
ADC0_CH12 I
P5.13
ADC0_CH13 I
I
In/A Bit 12 of Port 5, General Purpose Input
In/A Analog Input Channel 12 for ADC0
48
I
In/A Bit 13 of Port 5, General Purpose Input
In/A Analog Input Channel 13 for ADC0
EX0BINB
P5.14
I
I
In/A External Interrupt Trigger Input
49
50
51
In/A Bit 14 of Port 5, General Purpose Input
In/A Analog Input Channel 14 for ADC0
ADC0_CH14 I
P5.15
I
In/A Bit 15 of Port 5, General Purpose Input
In/A Analog Input Channel 15 for ADC0
ADC0_CH15 I
P2.12
O0 / I St/B Bit 12 of Port 2, General Purpose Input/Output
U0C0_
SELO4
O1
St/B USIC0 Channel 0 Select/Control 4 Output
St/B USIC0 Channel 1 Select/Control 3 Output
St/B External Bus Interface READY Input
U0C1_
SELO3
O2
I
READY
P2.11
52
O0 / I St/B Bit 11 of Port 2, General Purpose Input/Output
U0C0_
SELO2
O1
O2
OH
St/B USIC0 Channel 0 Select/Control 2 Output
U0C1_
SELO2
St/B USIC0 Channel 1 Select/Control 2 Output
BHE/WRH
St/B External Bus Interf. High-Byte Control Output
Can operate either as Byte High Enable (BHE) or
as Write strobe for High Byte (WRH).
53
55
P11.5
P2.0
O0 / I St/B Bit 5 of Port 11, General Purpose Input/Output
O0 / I St/B Bit 0 of Port 2, General Purpose Input/Output
O2 / I St/B CCU63 Channel 0 Input/Output
CCU63_
CC60
AD13
OH / I St/B External Bus Interface Address/Data Line 13
RxDC0C
I
St/B CAN Node 0 Receive Data Input
Data Sheet
14
V0.91, 2007-02
Draft Version
