XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
General Device Information
Table 2
Pin Definitions and Functions (cont’d)
Pin Symbol
Ctrl. Type Function
13
14
16
P8.1
O0 / I St/B Bit 1 of Port 8, General Purpose Input/Output
O1 / I St/B CCU60 Channel 1 Input/Output
CCU60_
CC61
P8.0
O0 / I St/B Bit 0 of Port 8, General Purpose Input/Output
O1 / I St/B CCU60 Channel 0 Input/Output
CCU60_
CC60
P6.0
O0 / I St/A Bit 0 of Port 6, General Purpose Input/Output
EMUX0
O1
St/A External Analog MUX Control Output 0
St/A USIC1 Channel 1 Shift Data Output
St/A OCDS Break Signal Output
U1C1_DOUT O2
BRKOUT
O3
I
ADCx_
St/A External Request Gate Input for ADC0/1
REQGTyC
U1C1_DX0E
P6.1
I
St/A USIC1 Channel 1 Shift Data Input
17
O0 / I St/A Bit 1 of Port 6, General Purpose Input/Output
EMUX1
T3OUT
O1
O2
St/A External Analog MUX Control Output 1
St/A GPT1 Timer T3 Toggle Latch Output
St/A USIC1 Channel 1 Shift Data Output
St/A External Request Trigger Input for ADC0/1
U1C1_DOUT O3
ADCx_
I
REQTRyC
18
19
P6.2
O0 / I St/A Bit 2 of Port 6, General Purpose Input/Output
EMUX2
T6OUT
O1
O2
St/A External Analog MUX Control Output 2
St/A GPT2 Timer T6 Toggle Latch Output
St/A USIC1 Channel 1 Shift Clock Output
St/A USIC1 Channel 1 Shift Clock Input
U1C1_SCLK O3
U1C1_DX1C I
P6.3
O0 / I St/A Bit 3 of Port 6, General Purpose Input/Output
T3OUT
O2
O3
St/A GPT1 Timer T3 Toggle Latch Output
U1C1_
SELO0
St/A USIC1 Channel 1 Select/Control 0 Output
U1C1_DX2D I
St/A USIC1 Channel 1 Shift Control Input
ADCx_
I
St/A External Request Trigger Input for ADC0/1
REQTRyD
Data Sheet
11
V0.91, 2007-02
Draft Version
