TLE9879QXA40
Electrical Characteristics
7) Keep current: Limit the current through this pin to the indicated value so that the enabled pull device can keep the default
pin level: VPIN ≥ VIH for a pull-up; VPIN ≤ VIL for a pull-down.
Force current: Drive the indicated minimum current through this pin to change the default pin level driven by the enabled
pull device: VPIN ≤ VIL for a pull-up; VPIN≥ VIH for a pull-down.
These values apply to the fixed pull-devices in dedicated pins and to the user-selectable pull-devices in general purpose
IO pins.
29.5.3
DC Parameters of Port 2
These parameters apply to the IO voltage range, 4.5 V ≤ VDDP ≤ 5.5 V.
Note:Operating Conditions apply.
Keeping signal levels within the limits specified in this table ensures operation without overload conditions.
For signal levels outside these specifications, also refer to the specification of the overload current IOV.
Table 31
DC Characteristics Port 2
VS = 5.5 V to 28 V, Tj = -40 °C to +150 °C, all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
–
Unit Note /
Test Condition
Number
Min.
Max.
Input low voltage
Input low voltage
Input high voltage
Input high voltage
Input hysteresis
VIL
-0.3
0.3 x VDDP
V
1)4.5V ≤ VDDP
5.5V
2)2.6V ≤ VDDP
4.5V
1)4.5V ≤ VDDP
5.5V
2)2.6V ≤ VDDP
≤
≤
≤
≤
P_5.2.1
P_5.2.10
P_5.2.2
P_5.2.11
P_5.2.3
VIL_extend -0.3
0.42 x
VDDP
–
V
VIH
0.7 x VDDP
–
V
DDP + 0.3 V
VIH_extend
HYSP2
–
0.52 x VDDP + 0.3 V
VDDP
4.5V
0.11 x VDDP
–
–
V
2)Series
resistance = 0 Ω;
4.5V ≤ VDDP
≤
5.5V
Input hysteresis
HYSP2_ext
–
0.09 x
–
V
2)Series
P_5.2.12
VDDP
resistance = 0 Ω;
2.6V ≤ VDDP <
4.5V
end
Input leakage current
Pull level keep current
Pull level force current
IOZ1
IPLK
IPLF
CIO
-400
-30
-750
–
–
–
–
–
+400
+30
+750
10
nA TJ ≤ 85°C,
0 V < VIN < VDDP
µA 3) VPIN ≥ VIH (up) P_5.2.5
PIN ≤ VIL (dn)
µA 3) VPIN ≤ VIL (up) P_5.2.6
P_5.2.4
V
VPIN ≥ VIH (dn)
2)
Pin capacitance
pF
P_5.2.7
(digital inputs/outputs)
1) Tested at VDDP = 5V, specified for 4.5V < VDDP < 5.5V.
2) Not subject to production test, specified by design.
3) Keep current: Limit the current through this pin to the indicated value so that the enabled pull device can keep the default
pin level: VPIN ≥ VIH for a pull-up; VPIN ≤ VIL for a pull-down.
Force current: Drive the indicated minimum current through this pin to change the default pin level driven by the enabled
pull device: VPIN ≤ VIL for a pull-up; VPIN≥ VIH for a pull-down.
Data Sheet
99
Rev. 1.0, 2015-04-30
