TDA5235
Functional Description
Please note that for Data Slicer Bit Mode a special constellation of RUNIN bits and TSI
bits has to be ensured. Further details can be seen at the end of Chapter 2.4.8.4.
The two independent correlators can be configured in the x_TSIMODE register to work
in one of the following four TSI modes:
16-Bit Mode: As a single correlator of up to 32 chips
The length of the x_TSILENA register must be set to 16d whenever x_TSILENB is higher
than 0.
x_TSILENA = 16d, x_TSILENB = 6d
RunIn
0 0 0 0 0 1 0 1 0 0 0 1 1 1 1 1 0 1 0 0 1 0
Incoming Pattern
0 1 0 1 0 1 0 1 0 1 1 0 0 1 1 0 0 1 0 1 0 1 1 0 1 0 1 0 1 0 1 0 0 1 1 0 0 1 0 1 1 0 0 1
Manchester Coded
x_TSIPTB x_TSIPTA
4 3 2 1 0 151413121110 9 8 7 6 5 4 3 2 1 0
5
TSI Pattern Match
FSYNC
0110011001010110101010
Data into FIFO
1 0 1 0 0 1 0
Figure 27
16-Bit TSI Mode
8-Bit Parallel Mode: As two correlators of up to 16 chips length each
working simultaneously in parallel
In the following example, TSI Pattern B matches first and generates an FSYNC. The
lengths of both TSI Patterns are now independent from each other. The payload length
for these two TSI Pattern may be different.
x_TSILENA = 16d, x_TSILENB = 6d
RunIn
Incoming Pattern
0 0 0 0 0 1 0 1 0 1 0 0 1 0
Manchester Coded
TSI Pattern B Match
0 1 0 1 0 1 0 1 0 1 1 0 0 1 1 0 0 1 1 0 0 1 0 1 1 0 0 1
x_TSIPTB
5 4 3 2 1 0
011001
FSYNC
Data into FIFO
1 0 1 0 0 1 0
Figure 28
8-Bit Parallel TSI Mode
Data Sheet
57
V1.0, 2010-02-19
