TDA5235
Appendix
Register Description
Field
Bits
Type
Description
PP3CFG
7:4
w
Port Pin 3 Output Signal Selection
0000B n.u.
0001B RX_RUN
0010B NINT
0011B LOW
0100B HIGH
0101B DATA
0110B DATA_MATCHFIL
0111B n.u.
1000B CH_DATA
1001B CH_STR
1010B RXD
1011B RXSTR
1100B n.u.
1101B n.u.
1110B n.u.
1111B n.u.
Reset: 1H
PP2CFG
3:0
w
Port Pin 2 Output Signal Selection
0000B CLK_OUT
0001B RX_RUN
0010B NINT
0011B LOW
0100B HIGH
0101B DATA
0110B DATA_MATCHFIL
0111B n.u.
1000B CH_DATA
1001B CH_STR
1010B RXD
1011B RXSTR
1100B n.u.
1101B n.u.
1110B n.u.
1111B n.u.
Reset: 2H
PPx Port Configuration Register
PPCFG2
Offset
083H
Reset Value
00H
PPx Port Configuration Register
Data Sheet
228
V1.0, 2010-02-19
