TDA5235
Appendix
Register Description
Field
Bits
Type
Description
DATLEN
7:0
w
Length of Data Field in Telegram, only valid when EOM criterion is
EOMDATLEN
Counting of number of payload bits starts after the last TSI Bit. EOM will
be generated after the last payload bit.
In 8-bit extended TSI mode, the value must be the payload length + 1,
because of the additional bit inserted (matching information).
Min: 00h = 256 payload bits
Reg. value 01h = 1 payload bit
Max: FFh = 255 payload bits
Reset: 00H
EOM Data Length Limit Parallel Mode Register
A_EOMDLENP
Offset
057H
Reset Value
00H
EOM Data Length Limit Parallel Mode
Register
ꢀ
ꢁ
'$7/(13
Z
Field
Bits
Type
Description
DATLENP
7:0
w
Length of Data Field in Telegram in Parallel Mode for TSI Pattern B,
only valid when EOM criterion is EOMDATLEN
Counting of number of payload bits starts after the last TSI Bit. EOM will
be generated after the last payload bit.
In 8-bit extended TSI mode, the value must be the payload length + 1,
because of the additional bit inserted (matching information).
Min: 00h = 256 payload bits
Reg. value 01h = 1 payload bit
Max: FFh = 255 payload bits
Reset: 00H
Channel Configuration Register
A_CHCFG
Offset
058H
Reset Value
04H
Channel Configuration Register
Data Sheet
222
V1.0, 2010-02-19
