TDA5235
Appendix
Register Description
ꢀ
ꢁ
76,37$ꢁ
Z
Field
TSIPTA1
Bits
Type
Description
7:0
w
Data Pattern for TSI comparison: Bit 15(MSB)...Bit 8 (in Chips)
Reset: 00H
TSI Pattern Data Reference B Register 0
A_TSIPTB0
Offset
053H
Reset Value
00H
TSI Pattern Data Reference B Register 0
ꢀ
ꢁ
76,37%ꢀ
Z
Field
Bits
Type
Description
TSIPTB0
7:0
w
Data Pattern for TSI comparison: Bit 7...Bit 0(LSB) (in Chips)
Reset: 00H
TSI Pattern Data Reference B Register 1
A_TSIPTB1
Offset
054H
Reset Value
00H
TSI Pattern Data Reference B Register 1
ꢀ
ꢁ
76,37%ꢁ
Z
Field
Bits
Type
Description
TSIPTB1
7:0
w
Data Pattern for TSI comparison: Bit 15(MSB)...Bit 8 (in Chips)
Reset: 00H
End Of Message Control Register
Data Sheet
220
V1.0, 2010-02-19
