TDA5235
Appendix
Register Description
Pre Decimation Factor Register
A_PDECF
Offset
039H
Reset Value
00H
Pre Decimation Factor Register
ꢀ
ꢃ
ꢁ
8186('
35('(&)
ꢂ
Z
Field
Bits
Type
Description
UNUSED
7
-
UNUSED
Reset: 0H
PREDECF
6:0
w
Predecimation Filter Decimation Factor
Predecimation Factor = PREDECF + 1
Reset: 00H
Pre Decimation Scaling Register FSK Mode
A_PDECSCFSK
Offset
03AH
Reset Value
00H
Pre Decimation Scaling Register FSK Mode
ꢀ
ꢃ
ꢈ
ꢄ
ꢁ
,1732/(
1)
5HV
3'6&$/()
Z
Z
Field
Bits
Type
Description
FSK Data Interpolation Enable
INTPOLENF
5
w
0B
1B
Disabled
Enabled
Reset: 0H
PDSCALEF
4:0
w
Predecimation Block Scaling Factor for FSK
Min 00h : 2^-10
Max 17h : 2^13
Reset: 00H
Pre Decimation Scaling Register ASK Mode
Data Sheet
205
V1.0, 2010-02-19
