TDA5235
Appendix
Register Description
Field
Bits
Type
Description
SIGDETSAT
7:0
w
Saturation threshold of the Sigdet peak detector used for zero-tube
threshold calculation.
Reset: 10H
Wake-up on Level Observation Time Register
A_WULOT
Offset
025H
Reset Value
00H
Wake-up on Level Observation Time Register
ꢀ
ꢈ
ꢄ
ꢁ
:8/2736
:8/27
Z
Z
Field
WULOTPS
Bits
Type
w
Description
7:5
Wake-Up Level Observation Time PreScaler
000B
001B
4
8
010B 16
011B 32
100B 64
101B 128
110B 256
111B 512
Reset: 0H
WULOT
4:0
w
Wake-Up Level Observation Time
Min. 01h : Twulot = 1 * WULOTPS * 64 / Fsys
Max 1Fh : Twulot = 31 * WULOTPS * 64 / Fsys
Value 00h : Twulot = 32 * WULOTPS * 64 / Fsys
Reset: 00H
Synchronization Search Time-Out Register
A_SYSRCTO
Offset
026H
Reset Value
87H
Synchronization Search Time-Out Register
ꢀ
ꢁ
6<65&72
Z
Data Sheet
193
V1.0, 2010-02-19
