TDA5235
Appendix
Register Description
Field
Bits
Type
Description
SYSRCTO
7:0
w
Synchronization search time out
FFh: 15 15/16 bit
00h: 0 bit
Reset: 87H
SYNC Timeout Timer Register
A_TOTIM_SYNC
Offset
027H
Reset Value
FFH
SYNC Timeout Timer Register
ꢀ
ꢁ
727,06<1&
Z
Field
Bits
Type
Description
TOTIMSYNC 7:0
w
Set value of Time-Out Timer (Symbol Synchronization)
Timer is used to get back from Run Mode Self Polling to the Self Polling
Mode whenever there is no Symbol Synchronization.
Timer is set back at new cycle start of Run Mode Self Polling.
TimeOut= (TOTIMSYNC * 64 * 512) / fsys
Min: 01h = (1 * 64 * 512)/ fsys
Max: FFh= (255 * 64 * 512) / fsys
00h: disabled
Reset: FFH
TSI Timeout Timer Register
A_TOTIM_TSI
Offset
028H
Reset Value
00H
TSI Timeout Timer Register
ꢀ
ꢁ
727,076,
Z
