TC1796
Electrical Parameters
4.2.5
Temperature Sensor
Table 19
Temperature Sensor Characteristics (Operating Conditions apply)
Parameter
Symbol
Values
Unit Note /
Test Cond
Min. Typ.
Max.
ition
Temperature
TSR
SR -40
150
°C
µs
°C
–
Sensor Range
Start-up time after
resets inactive
Sensor Inaccuracy TTSA
tTSST SR –
–
10
–
CC –
SR –
–
–
±10
10
–
A/D Converter clock fANA
MHz conversion
with ADC1
for DTS signal
Table 20
Parameter
Temperature Sensor Characteristics (Operating Conditions apply)
Symbol Typical Value Unit Note
Temperature of TTS CC TTS× = (ADC_Code - 487) 0.396 - 40 °C
10-bit ADC
the die at the
result
sensor location
TTS× = (ADC_Code - 1948) 0.099 - 40 °C
12-Bit ADC
result
Data Sheet
103
V1.0, 2008-04
