TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-7 Port 13 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

B15

P13.6

LVDS_TX General-purpose input

/ FAST /

GTM_TIM6_IN2_4

Mux input channel 2 of TIM module 6

PU1 /

VEXT /

ES6

GTM_TIM5_IN5_4

Mux input channel 5 of TIM module 5

GTM_TIM3_IN5_10

Mux input channel 5 of TIM module 3

P13.6

General-purpose output

GTM_TOUT255

GTM muxed output

—

Reserved

—

Reserved

—

Reserved

MSC2_SON

Data output - inverted part of the differential signal

—

Reserved

—

A15

P13.7

LVDS_TX General-purpose input

/ FAST /

GTM_TIM6_IN3_4

Mux input channel 3 of TIM module 6

PU1 /

VEXT /

ES6

GTM_TIM5_IN6_4

Mux input channel 6 of TIM module 5

GTM_TIM3_IN6_10

Mux input channel 6 of TIM module 3

P13.7

General-purpose output

GTM_TOUT256

GTM muxed output

—

Reserved

—

Reserved

—

Reserved

MSC2_SOP

Data output - direct part of the differential signal

—

Reserved

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
