TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-5 Port 11 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

J11

P11.15

SLOW /

PU1 /

VFLEX /

General-purpose input

Mux input channel 7 of TIM module 4

Mux input channel 7 of TIM module 0

Collision MII

GTM_TIM4_IN7_5

GTM_TIM0_IN7_8

GETH_COLA

P11.15

General-purpose output

GTM muxed output

Reserved

GTM_TOUT127

—

Reserved

Table 2-6 Port 12 Functions

Ball

Symbol

Ctrl. Buffer

Type

Function

K17

P12.0

SLOW /

PU1 /

VFLEX /

General-purpose input

Mux input channel 3 of TIM module 7

Mux input channel 0 of TIM module 4

Mux input channel 0 of TIM module 3

CAN receive input node 0

Receive Clock MII

CDTM4_DTM4

GTM_TIM7_IN3_2

GTM_TIM4_IN0_5

GTM_TIM3_IN0_7

CAN00_RXDC

GETH_RXCLKC

GTM_DTMA4_0

P12.0

General-purpose output

GTM muxed output

Reserved

GTM_TOUT128

—

Reserved

—

Reserved

—

Reserved

GETH_MDC

—

MDIO clock

Reserved

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
