    SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

    SAK-TC399XP-256F300S BC图片预览
    型号： SAK-TC399XP-256F300S BC
    PDF下载： 下载PDF文件 查看货源
    内容描述： [Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontrol­ler. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
    分类和应用：
    文件页数/大小： 548 页 / 21256 K
    品牌： INFINEON [ Infineon ]
     浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第458页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第459页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第460页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第461页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第463页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第464页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第465页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第466页
    TC39x BC/BD-Step
    Electrical SpecificationReset Timing
    3.14
    Reset Timing
    Table 3-30 Reset
    Parameter
    Symbol
    Values
    Typ.
    Unit
    Note / Test Condition
    Min.
    Max.
    Application Reset Boot Time
    System Reset Boot Time
    tB CC
    -
    -
    400
    µs
    operating with max.
    frequencies, with valid
    BMI header
    t
    BS CC
    -
    -
    -
    1.1
    3.1
    ms
    ms
    RAM initialization and
    HSM boot time are not
    included, with valid BMI
    header
    Cold Power on Reset Boot Time tBP CC
    -
    dVEXT/dT=1V/ms.
    VEXT>VLVDRST5.
    Boot time after Cold
    PORST including EVR
    ramp-up and Firmware
    execution time; RAM
    initialization and HSM
    boot time are not
    1)
    included.
    -
    -
    -
    1.6
    ms
    Firmware execution
    time after PORST
    release without EVR
    ramp-up; RAM
    initialization and HSM
    boot time is not
    included
    Minimum cold PORST reset
    hold time in case of power fail
    event issued by EVR primary
    monitors
    t
    EVRPOR CC 10 2)
    -
    µs
    PMS Infrastructure, EVRC and tEVRstartup
    EVR33 overall start-up time till CC
    cold PORST reset release
    -
    -
    -
    1
    -
    ms
    ms
    dV/dT=1V/ms. EVRC
    and EVR33 active
    Minimum PORST active hold
    time externally after power
    supplies are stable at operating
    levels after start-up
    t
    POA SR
    1 3)
    Configurable PORST digital
    filter delay in addition to analog
    pad filter delay
    t
    PORSTDF CC 600
    -
    1200
    ns
    Warm Reset Sequencing Delay tWARMRSTSEQ
    -
    -
    -
    180
    -
    µs
    ns
    CC
    HWCFG pins hold time from
    ESR0 rising edge
    t
    HDH CC
    16 / fSPB
    Data Sheet
    462
    V 1.2, 2021-03
    OPEN MARKET VERSION
