TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-3 Port 02 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

P02.9

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 2 of TIM module 4

Mux input channel 3 of TIM module 3

Mux input channel 2 of TIM module 0

Receive input channel 20

Receive input

GTM_TIM4_IN2_2

GTM_TIM3_IN3_10

GTM_TIM0_IN2_10

SENT_SENT20B

ASCLIN8_ARXA

P02.9

General-purpose output

GTM muxed output

Transmit output

GTM_TOUT116

ASCLIN2_ATX

IOM_MON2_14

IOM_REF2_14

ASCLIN8_ATX

—

Monitor input 2

Reference input 2

Transmit output

Reserved

CAN01_TXD

IOM_MON2_6

IOM_REF2_6

—

CAN transmit output node 1

Monitor input 2

Reference input 2

Reserved

—

Reserved

L10

P02.10

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 3 of TIM module 4

Mux input channel 4 of TIM module 3

Mux input channel 3 of TIM module 0

Receive input

GTM_TIM4_IN3_2

GTM_TIM3_IN4_11

GTM_TIM0_IN3_10

ASCLIN2_ARXC

CAN01_RXDE

SENT_SENT21B

ASCLIN8_ARXB

P02.10

CAN receive input node 1

Receive input channel 21

Receive input

General-purpose output

GTM muxed output

Reserved

GTM_TOUT117

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
