TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-3 Port 02 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
L7
P02.7
I
FAST /
PU1 /
VEXT /
ES
General-purpose input
GTM_TIM3_IN1_10
GTM_TIM1_IN7_1
GTM_TIM0_IN7_1
CCU60_CC61INC
SENT_SENT1C
EDSADC_DSCIN3B
EDSADC_ITR4E
GPT120_T3EUDA
PSI5_RX2B
Mux input channel 1 of TIM module 3
Mux input channel 7 of TIM module 1
Mux input channel 7 of TIM module 0
T12 capture input 61
Receive input channel 1
Modulator clock input, channel 3
Trigger/Gate input, channel 4
Count direction control input of core timer T3
RXD inputs (receive data) channel 2
Hall capture input 1
CCU60_CCPOS1A
QSPI3_SCLKA
CCU61_T13HRB
P02.7
Slave SPI clock inputs
External timer start 13
O0
O1
General-purpose output
GTM muxed output
GTM_TOUT7
IOM_REF0_7
Reference input 0
O2
O3
O4
O5
O6
O7
Reserved
QSPI3_SCLK
EDSADC_DSCOUT3
EVADC_EMUX01
SENT_SPC1
Master SPI clock output
Modulator clock output
Control of external analog multiplexer interface 0
Transmit output
CCU60_CC61
IOM_MON1_1
IOM_REF1_5
T12 PWM channel 61
Monitor input 1
Reference input 1
Data Sheet
43
V 1.2, 2021-03
OPEN MARKET VERSION
