TC39x BC/BD-Step

Electrical Specification5 V / 3.3 V switchable Pads

Table 3-8 Fast 3.3V GPIO (cont’d)

Parameter

Symbol

Values

Typ.

Unit

Note / Test Condition

Min.

Max.

Pull-up current ⁴⁾

_PUHCC

|17|

µA

V_IH; AL and TTL

(degraded, used for

CIF)

|11|

µA

V_IH; TTL

|80|

V_IL; AL and TTL and

TTL (degraded, used

for CIF)

Pull-down current ⁵⁾

_PDLCC

|105|

µA

V_IH; AL and TTL

(degraded, used for

CIF)

|115|

µA

V_IH; TTL

|19|

|15|

V_IL; AL and TTL

V_IL; TTL (degraded,

used for CIF)

Input leakage current

_OZCC

-1100

-2500

1100

2500

T_J≤ 150°C ; (0.1 *

V_{EXT/FLEX/EVRSB}) < V_IN<

(0.9 * V_{EXT/FLEX/EVRSB}

)

T_J≤ 150°C ; (0.1 *

_EXT/FLEX) < V_IN< (0.9 *

_EXT/FLEX) ; LVDS_TX /

Fast pad type

-6000

-3200

6000

3200

T_J≤ 150°C ; LVDS_RX

/ Fast pad type ; else

T_J≤ 150°C ; LVDS_TX

/ Fast pad type ; else

-1500

-2000

1500

2000

T_J≤ 150°C ; else

T_J≤ 170°C ; (0.1 *

V_{EXT/FLEX/EVRSB}) < V_IN<

(0.9 * V_{EXT/FLEX/EVRSB}

)

-4000

4000

T_J≤ 170°C ; (0.1 *

_EXT/FLEX) < V_IN< (0.9 *

_EXT/FLEX) ; LVDS_TX /

Fast pad type

-13500

-5100

-2500

13500

5100

2500

T_J≤ 170°C ; LVDS_RX

/ Fast pad type ; else

T_J≤ 170°C ; LVDS_TX

/ Fast pad type ; else

T_J≤ 170°C ; else

Data Sheet

417

V 1.2, 2021-03

OPEN MARKET VERSION
