TC39x BC/BD-Step

Electrical Specification5 V / 3.3 V switchable Pads

Table 3-10 Slow 3.3V GPIO (cont’d)

Parameter

Symbol

Values

Typ.

Unit

Note / Test Condition

Min.

Max.

Pull-up current ⁴⁾

_PUHCC

|17|

µA

V_IH; AL and TTL

(degraded, used for

CIF); exept VGATE1P;

except VGATE1N and

T_J> 150°C

|11|

µA

V_IH; TTL; exept

VGATE1P; except

VGATE1N and T_J>

150°C

|80|

V_IL; AL and TTL and

TTL (degraded, used

for CIF); exept

VGATE1P; except

VGATE1N and T_J>

150°C

Pull-down current ⁵⁾

_PDLCC

|105|

µA

V_IH; AL and TTL

(degraded, used for

CIF)

|115|

µA

V_IH; TTL

|19|

|15|

V_IL; AL and TTL

V_IL; TTL (degraded,

used for CIF)

Input leakage current

_OZCC

-300

300

T_J≤ 150°C; (0.1 *

V_{EXT/FLEX/EVRSB}) < V_IN<

(0.9 * V_{EXT/FLEX/EVRSB}

)

-400

-600

400

600

T_J≤ 150°C; else

T_J≤ 170°C; (0.1 *

V_{EXT/FLEX/EVRSB}) < V_IN<

(0.9 * V_{EXT/FLEX/EVRSB}

)

-750

750

T_J≤ 170°C; else

-18000

18000

P32.0 and

P32.1;T_J≤150°C

-38000

38000

P32.0 and

P32.1;T_J≤170°C

Input high voltage level

V_IHSR

0.7 *

V_EXT/FLEX/E

VRSB

2.0

TTL

1.4

TTL (degraded, used

for CIF)

Data Sheet

421

V 1.2, 2021-03
