TC39x BC/BD-Step

Electrical SpecificationPin Reliability in Overload

Table 3-2 Overload Parameters (cont’d)

Parameter

Symbol

Values

Typ.

Unit

Note / Test Condition

Min.

Max.

Overload coupling factor for

digital inputs, negative

_OVDNCC

3*10^-4

Overload injected on

GPIO non LVDS pad

and affecting neighbor

fast pads; -5mA < I_IN<

0mA

2*10^-3

Overload injected on

GPIO non LVDS pad

and affecting neighbor

slow pads VGASTE1N

and VGATE1P; -5mA <

I_IN< 0mA

1*10^-4

Overload injected on

GPIO non LVDS pad

and affecting neighbor

slow pads; -5mA < I_IN<

0mA

0.8

Overload injected on

LVDS RX pad and

affecting neighbor

LVDS pads

0.5

Overload injected on

LVDS TX pad and

affecting neighbor

LVDS pads

Overload coupling factor for

digital inputs, positive

_OVDPCC

1.5*10^-3

Overload injected on

GPIO non LVDS pad

and affecting neighbor

GPIO non LVDS pads

Overload injected on

LVDS RX pad and

affecting neighbor

LVDS pads

5*10^-3

1*10^-4

1*10^-5

Overload injected on

LVDS TX pad and

affecting neighbor

LVDS pads

Overload coupling factor for

analog inputs, negative ²⁾

_OVANCC

Analog inputs overlaid

with slow pads or pull

down diagnostics; -

5mA < I_IN< 0mA

else; -5mA < I_IN< 0mA

Data Sheet

408

V 1.2, 2021-03

OPEN MARKET VERSION
