TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-292 ADAS Package Variant Pin
Table 2-60 Analog Inputs (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
U10
AN1
I
I
I
I
I
I
I
I
I
I
I
I
D / HighZ Analog Input 1
/ VDDM
EVADC_G0CH1
EDSADC_EDS3NA
AN2
Analog input channel 1, group 0
Negative analog input channel 3, pin A
D / HighZ Analog Input 2
W9
U9
T9
/ VDDM
EVADC_G0CH2
EDSADC_EDS0PA
AN3
Analog input channel 2, group 0
Positive analog input channel 0, pin A
D / HighZ Analog Input 3
/ VDDM
EVADC_G0CH3
EDSADC_EDS0NA
AN4
Analog input channel 3, group 0
Negative analog input channel 0, pin A
D / HighZ Analog Input 4
/ VDDM
EVADC_G11CH0
EVADC_G0CH4
AN5
Analog input channel 0, group 11
Analog input channel 4, group 0
Y9
T8
D / HighZ Analog Input 5
/ VDDM
EVADC_G11CH1
EVADC_G0CH5
AN6
Analog input channel 1, group 11
Analog input channel 5, group 0
D / HighZ Analog Input 6
/ VDDM
EVADC_G11CH2
EVADC_G0CH6
AN7
Analog input channel 2, group 11
Analog input channel 6, group 0
U8
W8
U7
Y8
W7
T7
D / HighZ Analog Input 7
/ VDDM
EVADC_G11CH3
EVADC_G0CH7
AN8
Analog input channel 3, group 11
Analog input channel 7, group 0
D / HighZ Analog Input 8
/ VDDM
EVADC_G11CH4
EVADC_G1CH0
AN9
Analog input channel 4, group 11
Analog input channel 0, group 1
D / HighZ Analog Input 9
/ VDDM
EVADC_G11CH5
EVADC_G1CH1
AN10
Analog input channel 5, group 11
Analog input channel 1, group 1
D / HighZ Analog Input 10
/ VDDM
EVADC_G11CH6
EVADC_G1CH2
AN11
Analog input channel 6, group 11
Analog input channel 2, group 1
D / HighZ Analog Input 11
/ VDDM
EVADC_G11CH7
EVADC_G1CH3
AN12
Analog input channel 7, group 11
Analog input channel 3, group 1
D / HighZ Analog Input 12
/ VDDM
EVADC_G1CH4
EDSADC_EDS0PB
Analog input channel 4, group 1
Positive analog input channel 0, pin B
