SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

SAK-TC399XP-256F300S BC图片预览
型号: SAK-TC399XP-256F300S BC
PDF下载: 下载PDF文件 查看货源
内容描述: [Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontrol­ler. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
分类和应用:
文件页数/大小: 548 页 / 21256 K
品牌: INFINEON [ Infineon ]
 浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第106页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第107页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第108页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第109页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第111页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第112页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第113页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第114页
TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-14 Port 24 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
U30
P24.1
I
FAST /
PU1 /
VEBU /
ES
General-purpose input
Mux input channel 1 of TIM module 6
Mux input channel 1 of TIM module 4
Address Input
GTM_TIM6_IN1_6
GTM_TIM4_IN1_8
EBU_A_IN15
P24.1
O0
O1
O2
O3
O4
O5
O6
O7
O
General-purpose output
GTM muxed output
Reserved
GTM_TOUT223
Reserved
Reserved
Reserved
Reserved
Reserved
EBU_A15
Address Output
General-purpose input
Mux input channel 2 of TIM module 6
Mux input channel 2 of TIM module 4
Address Input
T29
P24.2
I
FAST /
PU1 /
VEBU /
ES
GTM_TIM6_IN2_6
GTM_TIM4_IN2_8
EBU_A_IN14
P24.2
O0
O1
O2
O3
O4
O5
O6
O7
O
General-purpose output
GTM muxed output
Reserved
GTM_TOUT224
Reserved
Reserved
Reserved
Reserved
Reserved
EBU_A14
Address Output
Data Sheet
110
V 1.2, 2021-03
OPEN MARKET VERSION
