TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-13 Port 23 Functions
Ball Symbol
Ctrl. Buffer
Type
Function
AC25 P23.0
GTM_TIM6_IN7_1
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 7 of TIM module 6
Mux input channel 5 of TIM module 1
Mux input channel 5 of TIM module 0
CAN receive input node 0
General-purpose output
GTM muxed output
GTM_TIM1_IN5_4
GTM_TIM0_IN5_4
CAN10_RXDC
P23.0
O0
O1
O2
O3
O4
O5
O6
O7
I
GTM_TOUT41
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
AB24 P23.1
FAST /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 6 of TIM module 6
Mux input channel 6 of TIM module 1
Mux input channel 6 of TIM module 0
Upstream assynchronous input signal
Receive input
GTM_TIM6_IN6_1
GTM_TIM1_IN6_4
GTM_TIM0_IN6_4
MSC1_SDI0
ASCLIN6_ARXF
P23.1
O0
O1
O2
O3
O4
O5
O6
O7
General-purpose output
GTM muxed output
GTM_TOUT42
ASCLIN1_ARTS
QSPI4_SLSO6
GTM_CLK0
Ready to send output
Master slave select output
CGM generated clock
CAN transmit output node 0
External Clock 0
CAN10_TXD
CCU_EXTCLK0
ASCLIN6_ASCLK
Shift clock output
Data Sheet
106
V 1.2, 2021-03
OPEN MARKET VERSION
