TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-14 Port 24 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
N30
P24.9
I
FAST /
PU1 /
VEBU /
ES
General-purpose input
Mux input channel 1 of TIM module 7
Mux input channel 1 of TIM module 5
Address Input
GTM_TIM7_IN1_5
GTM_TIM5_IN1_6
EBU_A_IN6
P24.9
O0
O1
O2
O3
O4
O5
O6
O7
O
General-purpose output
GTM muxed output
Reserved
GTM_TOUT231
Reserved
Reserved
Reserved
Reserved
Reserved
EBU_A6
Address Output
General-purpose input
Mux input channel 2 of TIM module 7
Mux input channel 2 of TIM module 5
Address Input
M29
P24.10
I
FAST /
PU1 /
VEBU /
ES
GTM_TIM7_IN2_4
GTM_TIM5_IN2_5
EBU_A_IN4
P24.10
O0
O1
O2
O3
O4
O5
O6
O7
O
General-purpose output
GTM muxed output
Reserved
GTM_TOUT232
Reserved
Reserved
Reserved
Reserved
Reserved
EBU_A4
Address Output
Data Sheet
114
V 1.2, 2021-03
OPEN MARKET VERSION
