TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-13 Port 23 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AB25 P23.2

GTM_TIM6_IN5_1

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 5 of TIM module 6

Mux input channel 6 of TIM module 1

Mux input channel 6 of TIM module 0

Receive input

GTM_TIM1_IN6_5

GTM_TIM0_IN6_5

ASCLIN7_ARXC

P23.2

General-purpose output

GTM muxed output

GTM_TOUT43

—

Reserved

—

Reserved

CAN23_TXD

CAN transmit output node 3

CAN transmit output node 2

Reserved

CAN12_TXD

—

Reserved

AA24 P23.3

SLOW /

PU1 /

VEXT /

General-purpose input

Mux input channel 4 of TIM module 6

Mux input channel 7 of TIM module 1

Mux input channel 7 of TIM module 0

Injection signal from port

Receive input

GTM_TIM6_IN4_2

GTM_TIM1_IN7_4

GTM_TIM0_IN7_4

MSC1_INJ0

ASCLIN6_ARXA

CAN12_RXDC

CAN23_RXDB

P23.3

CAN receive input node 2

CAN receive input node 3

General-purpose output

GTM muxed output

GTM_TOUT44

ASCLIN7_ATX

—

Transmit output

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

Data Sheet

107

V 1.2, 2021-03

OPEN MARKET VERSION
