TC1767
Introduction
Features
• Full-duplex asynchronous operating modes
– 8-bit or 9-bit data frames, LSB first
– Parity-bit generation/checking
– One or two stop bits
– Baud rate from 5.0 Mbit/s to 1.19 bit/s (@ 80 MHz module clock)
– Multiprocessor mode for automatic address/data byte detection
– Loop-back capability
• Half-duplex 8-bit synchronous operating mode
– Baud rate from 10.0 Mbit/s to 813.8 bit/s (@ 80 MHz module clock)
• Double-buffered transmitter/receiver
• Interrupt generation
– On a transmit buffer empty condition
– On a transmit last bit of a frame condition
– On a receive buffer full condition
– On an error condition (frame, parity, overrun error)
• Implementation features
– Connections to DMA Controller
– Connections of receiver input to GPTA (LTC) for baud rate detection and LIN break
signal measuring
2.4.2
High-Speed Synchronous Serial Interfaces
The TC1767 includes two High-Speed Synchronous Serial Interfaces, SSC0 and SSC1.
Both SSC modules have the same functionality.
Figure 6 shows a global view of the Synchronous Serial interface (SSC).
Data Sheet
31
V1.3, 2009-09
