TC1767
Introduction
2.4
On-Chip Peripheral Units
The TC1767 micro controller offers several versatile on-chip peripheral units such as
serial controllers, timer units, and Analog-to-Digital converters. Several I/O lines on the
TC1767 ports are reserved for these peripheral units to communicate with the external
world.
On-Chip Peripheral Units
• Two Asynchronous/Synchronous Serial Channels (ASC) with baud-rate generator,
parity, framing and overrun error detection
• Two Synchronous Serial Channels (SSC) with programmable data length and shift
direction
• One Micro Second Bus Interface (MSC) for serial communication
• One CAN Module (MultiCAN) for high-efficiency data handling via FIFO buffering and
gateway data transfer
• One Micro Link Serial Bus Interfaces (MLI) for serial multiprocessor communication
• One General Purpose Timer Array (GPTA) with a powerful set of digital signal filtering
and timer functionality to accomplish autonomous and complex Input/Output
management
• Two Analog-to-Digital Converter Units (ADC0, ADC1) with 8-bit, 10-bit, or 12-bit
resolution.
• One fast Analog-to-Digital Converter Unit (FADC)
2.4.1
Asynchronous/Synchronous Serial Interfaces
The TC1767 includes two Asynchronous/Synchronous Serial Interfaces, ASC0 and
ASC1. Both ASC modules have the same functionality.
Figure 5 shows a global view of the Asynchronous/Synchronous Serial Interface (ASC).
