11.6 DC Characteristics
S29GL-P DC Characteristics (CMOS Compatible)
Parameter
Symbol
Parameter Description
(Notes)
Ty
p
Test Conditions
VIN = VSS to VCC
Min
Max
±5.0
±2.0
35
Unit
WP/ACC
Others
µA
ILI
Input Load Current
VCC = VCC max
ILIT
ILO
µA
µA
A9 Input Load Current
Output Leakage Current
VCC = VCC max; A9 = 12.5 V
±1.0
VOUT = VSS to VCC , VCC = VCC max
CE# = VIL, OE# = VIH, VCC = VCCmax, f = 1
MHz
6
20
55
CE# = VIL, OE# = VIH, VCC = VCCmax, f = 5
MHz
ICC1
30
mA
VCC Active Read Current (1)
VIO Non-Active Output
CE# = VIL, OE# = VIH, VCC = VCCmax, f = 10
MHz
60
0.2
1
110
10
IIO2
mA
mA
CE# = VIL, OE# = VIH
CE# = VIL, OE# = VIH, VCC = VCCmax, f = 10
MHz
10
VCC Intra-Page Read Current
(1)
ICC2
CE# = VIL, OE# = VIH, VCC = VCCmax, f = 33
MHz
5
20
90
VCC Active Erase/
Program Current (2, 3)
ICC3
50
mA
µA
CE# = VIL, OE# = VIH, VCC = VCCmax
CE#, RESET# = VCC ± 0.3 V,
OE# = VIH, VCC = VCCmax
ICC4
1
5
VCC Standby Current
VIL = VSS + 0.3 V/-0.1V,
VCC = VCCmax; VIL = VSS + 0.3 V/-0.1V,
RESET# = VSS ± 0.3 V
ICC5
250
1
500
5
µA
µA
VCC Reset Current
VCC = VCCmax, VIH = VCC ± 0.3 V,
ICC6
Automatic Sleep Mode (4)
VIL = VSS + 0.3 V/-0.1V, WP#/ACC = VIH
WP#/ACC pin
10
50
20
ACC Accelerated
Program Current
CE# = VIL, OE# = VIH,
VCC = VCCmax, WP#/ACC = VHH
IACC
mA
VCC pin
80
VIL
VIH
Input Low Voltage (5)
Input High Voltage (5)
–0.1
0.3 x VIO
VIO + 0.3
V
V
0.7 x VIO
Voltage for Program
Acceleration
VHH
VID
11.5
11.5
12.5
V
V
V
CC = 2.7 –3.6 V
CC = 2.7 –3.6 V
Voltage for Autoselect and
Temporary Sector Unprotect
V
12.5
VOL
VOH
VLKO
0.15 x VIO
V
V
V
Output Low Voltage (5)
IOL = 100 µA
IOH = -100 µA
0.85 x VIO
2.3
Output High Voltage (5)
Low VCC Lock-Out Voltage (3)
2.5
Notes
1. The ICC current listed is typically less than 2 mA/MHz, with OE# at VIH
.
2. ICC active while Embedded Erase or Embedded Program or Write Buffer Programming is in progress.
3. Not 100% tested.
4. Automatic sleep mode enables the lower power mode when addresses remain stable tor tACC + 30 ns.
5. VIO = 1.65–3.6 V
6. VCC = 3 V and VIO = 3V or 1.8V. When VIO is at 1.8V, I/O pins cannot operate at 3V.
