S29GL01GP
S29GL512P
S29GL256P
S29GL128P
11.2 Operating Ranges
Specifications
Range
Ambient Temperature (TA), Industrial (I) Device
Ambient Temperature (TA), Commercial (C) Device
–40°C to +85°C
0°C to +85°C
+2.7 V to 3.6 V or
+3.0 V to 3.6 V
Supply Voltages
VCC
VIO
VIO Supply Voltages
+1.65 V to VCC
Notes
1. Operating ranges define those limits between which the functionality of the device is guaranteed.
2. See also Ordering Information on page 4.
3. For valid V /V range combinations, see Ordering Information on page 4. The I/Os do not operate at 3 V when V = 1.8 V.
CC IO
IO
11.3 Test Conditions
Figure 11.3 Test Setup
Device
Under
Test
C
L
Test Specifications
Test Condition
All Speeds
Unit
Output Load Capacitance, CL
(including jig capacitance)
30
pF
Input Rise and Fall Times
Input Pulse Levels
5
ns
V
0.0–VIO
0.5VIO
0.5 VIO
Input timing measurement reference levels (See Note)
Output timing measurement reference levels
Note
V
V
If VIO < VCC, the reference level is 0.5 VIO
.
Document Number: 002-00886 Rev. *B
Page 49 of 83
