IKZA50N120CH7
™
High speed 1200 V TRENCHSTOP IGBT 7 Technology
4 Characteristics diagrams
Typical switching times as a function of junction
temperature
Typical switching energy losses as a function of
collector current
t = f(Tvj)
E = f(IC)
IC = 50 A, VCC = 600 V, VGE = 0/15 V, RG = 8 Ω
VCC = 600 V, Tvj = 175 °C, VGE = 0/15 V, RG = 8 Ω
10000
1000
100
10
9
8
7
6
5
4
3
2
1
0
1
25
50
75
100
125
150
175
0
10 20 30 40 50 60 70 80 90 100
Typical switching energy losses as a function of gate
resistor
Typical switching energy losses as a function of
junction temperature
E = f(RG)
E = f(Tvj)
IC = 50 A, VCC = 600 V, Tvj = 175 °C, VGE = 0/15 V
IC = 50 A, VCC = 600 V, VGE = 0/15 V, RG = 8 Ω
8
7
6
5
4
3
2
1
0
5
4
3
2
1
0
25
50
75
100
125
150
175
5
10
15
20
25
30
35
40
45
50
Datasheet
9
Revision 1.20
2023-01-19
