Quasi-Resonant, 800V CoolSET™ in DS0-12 Package
Electrical Characteristics
4.3.10
CoolMOS™ Section
Table 15
CoolMOS™ Section
Parameter
Symbol
Unit Test Condition
Limit Values
min.
typ.
max.
Drain Source Breakdown Voltage
Drain Source On-Resistance
V(BR)DSS
800
870
-
-
V
Tj = 25 °C
Tj = 110 °C
Ω
Ω
RDSon
-
1.00
2.24
1.11
2.46
Tj= 25 °C
Tj=125 °C1
at ID= 1.35 A
Effective output capacitance,
energy related1
Rise Time2
Fall Time2
Co(er)
-
-
-
24
30
30
-
-
-
pF
ns
ns
VDS = 0 V to 480 V
trise
tfall
1 The parameter is not subjected to production test - verified by design/characterization
2 Measured in a Typical Flyback Converter Application
Data Sheet
18
Revision 1.0
2016-05-12
