AIROC™ Bluetooth® system on chip for automotive applications
Specifications
11.2.7
Recommended component
Table 19
Recommended component
Conditions
Parameter
Min
0.5
Typ
2.2
Max
4.7
Unit
μF
External output capacitor, Total ESR (trace/cap): 5 m–240 mΩ
Co
External input capacitor
Only use an external input capacitor at
VDD_DIGLDO pin if it is not supplied from
CBUCK output.
–
1
2.2
11.2.8
Digital I/O characteristics
Table 20. Digital I/O characteristics
Characteristics
Symbol
VIL
VIH
VIL
VIH
VOL
VOH
Min
–
2.4
–
1.4
–
Typ
–
Max
0.8
–
0.4
–
0.4
–
Unit
V
Input low voltage (VDDO = 3 V)
Input high voltage (VDDO = 3 V)
Input low voltage (VDDO = 1.8 V)
Input high voltage (VDDO = 1.8 V)
Output low voltage
–
–
–
–
–
Output high voltage
VDDO –
0.4V
Input low current
Input high current
IIL
IIH
–
–
–
–
–
–
–
–
–
–
–
–
–
–
1.0
1.0
4.0
2.0
8.0
4.0
0.4
μA
Output low current (VDDO = 3 V, VOL = 0.4 V)
Output low current (VDDO = 3 V, VOL = 1.8 V)
Output high current (VDDO = 3 V, VOH = 2.6 V)
Output high current (VDDO = 1.8 V, VOH = 1.4 V)
Input capacitance
IOL
IOL
IOH
IOH
CIN
mA
pF
11.2.9
Current consumption
Table 21 provides the current consumption measurements taken at input of LDOIN and VDDIO combined
(LDOIN = VDDIO = 3.0 V).
Table 21
Current consumption
Operational mode
Conditions
Typ
1.3
2.55
5.9
22.0
16.5
8.7
Unit
48 MHz with Pause
48 MHz without Pause
Continuous RX
Continuous TX - 10.5 dBm
–
HCI
mA
RX
TX
PDS
ePDS
All RAM retained
32 kHz XTAL on
μA
HID-Off (SDS)
1.75
Datasheet
37
002-25826 Rev. *G
2022-09-24
