PROFET + 24V
BTT6200-4ESA
Protection functions
6.6
Electrical characteristics for the protection functions
Table 7
Electrical Characteristics: Protection
VS = 8 V to 36 V, TJ = -40°C to 150°C, (unless otherwise specified).
Typical values are given at VS = 28 V, TJ = 25°C
Parameter
Symbol
Values
Unit Note or Test
Condition
Number
Min.
Typ. Max.
Loss of ground
Output leakage current while
GND disconnected
IOUT(GND)
VDS(REV)
VS(AZ)
–
0.1
650
70
–
mA
mV
V
12)13)VS = 28 V
See Figure 15
P_6.6.1
P_6.6.2
P_6.6.3
Reverse polarity
Drain source diode voltage
during reverse polarity
200
65
700
75
14)IL = - 1 A
See Figure 18
Overvoltage
Overvoltage protection
ISOV = 5 mA
See Figure 17
Overload condition
15)
Load current limitation
IL5(SC)
9
–
11
80
14
–
A
K
V
= 5 V See
P_6.6.4
P_6.6.8
DS
Figure 19 and
Chapter 9.3
16)See Figure 19
Dynamic temperature increase ΔTJ(SW)
while switching
Thermal shutdown temperature TJ(SC)
150
–
170
30
200
–
°C
K
14)See Figure 19
13)
P_6.6.10
P_6.6.11
Thermal shutdown hysteresis
ΔTJ(SC)
12
All pins are disconnected except VS and OUT.
Not Subject to production test, specified by design.
Test at TJ = +150°C only.
Test at TJ = -40°C only.
Functional test only
13
14
15
16
Datasheet
25
Rev. 1.00
2019-03-09
