High Current PN Half Bridge
BTN8982TA
Package Outlines
7
Package Outlines
4.4
±0.2
10
±0.1
1.27
0...0.3
A
B
8.5 1)
0.05
2.4
0.1
0...0.15
±0.1
7 x 0.6
0.5±0.1
6 x 1.27
M
0.25
A B
8˚ MAX.
0.1 B
1) Typical
Metal surface min. X = 7.25, Y = 6.9
All metal surfaces tin plated, except area of cut.
GPT09114
Footprint
10.8
0.47
0.8
8.42
Figure 18 PG-TO263-7-1 (Plastic Green Transistor Single Outline Package)
Green Product (RoHS compliant)
To meet the world-wide customer requirements for environmentally friendly products and to be compliant with
government regulations the device is available as a green product. Green products are RoHS-Compliant (i.e
Pb-free finish on leads and suitable for Pb-free soldering according to IPC/JEDEC J-STD-020).
For further information on alternative packages, please visit our website:
Dimensions in mm
http://www.infineon.com/packages.
